| S.no | Specification | UNITS / DIMENSIONS |
|---|---|---|
| 1 | Rated Capacity (Q) | 1500 Kg |
| 2 | Lifting Height (h3) | 2500 mm |
| 3 | Load Center (C) | 500 mm |
| 4 | Max. Machine Height (h4) | 3060 mm |
| 5 | Handle Height (h2) | 1450 – 1460 mm |
| 6 | Fork Size (LXN) | 1150 X 160 mm |
| 7 | Width Over Forks (E) | 570 mm |
| 8 | Min. Turning Radius (WA) | 1620 mm |
| 9 | Wheel Base (Y) | 1340 mm |
| 10 | Front – Wheel Distance (X) | 339 mm |
| 11 | Max. Speed Without Load | 4.5~6 Km/h |
| 12 | Max. Speed With Load | 4~5 Km/h |
| 13 | Driving Motor | 24V / 1.2~3 Kw |
| 14 | Lifting Motor | 24V / 2~3 Kw |
| 15 | Aneroid Battery | 24V / 210 Exide |
| 16 | Charger | 24V / 30A |
| 17 | Overall Length (L) | 2000 mm |
| 18 | Overall Width (W) | 860 mm |
| 19 | Overall Height (h1) | 1830 mm |
| 20 | Overall Net Weight Approx | 695 Kg |
